Overview 1-3
How Do I Read the Catalog
Number?
Knowing your catalog number for the 1336 IMPACT drive, can help
you sort out what options you have, as well as helping you
communicate this information to the Allen-Bradley support
personnel. The catalog numbers all have the following form:
1 G frame drives in enclosed construction and all H frame drives are supplied only through the Configured Drives Program.
2D– G frame drives in IP 65 (NEMA Type 4) and IP 54 (NEMA Type 12) configurations are supplied through the Configured Drives Program.
Note: BPR indicates F frame roll-in units
1336E
First Position
Bulletin Number
mods
Sixth Position
Options
EN
Fifth Position
Language
Code Language
EN English/English
FR English/French
ES English/Spanish
DE English/German
IT English/Italian
PT English/
Portuguese
AA
Fourth Position
Enclosure Type
Code Type
AA NEMA 1 (IP20)
AE NEMA 1 (IP20)/
EMC
0.37–45 kW
(0.5–60 HP) only
AF NEMA 4 (IP65)
AJ NEMA 12 (IP54)
AN Open (IP00)
AQ
Second Position
Voltage
Letter Voltages
AQ 200–240VAC or 310VDC
BR 380–480VAC or 513±620VDC
CW 500–600VAC or 775VDC
A 200–240VAC
B 380–480VAC
BP 380–480VAC
(F Frame)
BX Special Rating
C 500–600VAC
Q 310VDC
R 513–620VDC
RX Special Rating
W 775VDC
F05
Third Position
Nominal HP Rating
Code kW (HP)
F05 0.37 (0.5)
F07 0.56 (0.75)
F10 0.75 (1)
F15 1.2 (1.5)
F20 1.5 (2)
F30 2.2 (3)
F50 3.7 (5)
F75 5.5 (7.5)
F100 7.5 (10)
007 5.5 (7.5)
010 7.5 (10)
015 11 (15)
020 15 (20)
025 18.5 (25)
030 22 (30)
040 30 (40)
050 37 (50)
060 45 (60)
075 56 (75)
100 75 (100)
125 93 (125)
150 112 (150)
200 149 (200)
250 187 (250)
300 224 (300)
350 261 (350)
400 298 (400)
450 336 (450)
500 373 (500)
600 448 (600)
650 485 (650)
700C 522 (700)
800C 597 (800)
or
Code Description
Human Interface Module, IP 20 (NEMA Type 1)
HAB Blank — No functionality
HAP Programmer Only
HA1 Programmer/Controller w/Analog Pot
HA2 Programmer/Controller w/Digital Pot
Human Interface Module, IP 65/54 (NEMA Type4/12)
HJP Programmer Only
HJ2 Programmer/Controller w/Digital Pot
Communication Options
GM1 Single Point Remote I/O
GM2 RS–232/422/485, DF1, & DH485
GM5 DeviceNet
TM
Control Interface Options
L4 TTL Contact
L7E TTL Contact & Encoder Feedback
L5 24VAC/DC
L8E 24VAC/DC & Encoder Feedback
L6 115VAC
L9E 115VAC & Encoder Feedback
1
2
1
1
1
1
1
1
1
1
2
