Starting Up Your System 6-11
Configuring the Analog Section Follow these steps to configure the analog section:
9.
Speed Ref 1
+500.2 RPM
If a speed reference is not already linked, you can enter a value to use as a preset speed.
For example, if there is a link to Speed Ref 1 (parameter 29), the start up procedure would
skip to Speed Ref 2 (parameter 31), or the next non-linked speed reference.
For each speed reference, press SEL.
Use INC or DEC to enter the value.
When the value is correct, press ENTER to return to the top line.
Press ENTER again.
Step 10
10.
Digital Config.
Complete ENTER
Press ENTER.
Step: At this prompt: You need to: Go to:
Step: At this prompt: You need to: Go to:
1.
Setup Reference
Analog/PPR IO? N
Press ENTER if you do not want to configure the analog section. Step 11
If yes, press INC or DEC to toggle the N to a Y. Press ENTER. Step 2
2.
Connect Inputs
to References? N
To connect the inputs, press INC or DEC to toggle the N to a Y. Press ENTER to connect
inputs to Speed Reference 1, speed Reference 2, Torque Reference, Current, or 4 –
20 mA.
Step 3
If no, press ENTER. Step 6
3.
Configure Speed
Reference #1? N
Press INC or DEC to toggle the N to a Y to configure Speed Reference 1.
Press ENTER. You can connect Speed Reference 1 to any ONE of the following: the HIM
pot, Analog In1, Analog In2, the 4 – 20 mA input, the MOP input, the Pulse Input, or the
gateway. Depending on which input you choose, you may be prompted for an offset and
scale value.
Step 4
If no, press ENTER.
4.
Configure Speed
Reference #2? N
Press INC or DEC to toggle the N to a Y to configure Speed Reference 2.
Press ENTER. You can connect Speed Reference 2 to any ONE of the following: the HIM
pot, Analog In1, Analog In2, the 4 – 20 mA input, the MOP input, the Pulse Input, or the
gateway. Depending on which input you choose, you may be prompted for additional
information.
Step 5
If no, press ENTER.
5.
Configure Torque
Reference? N
Press INC or DEC to toggle the N to a Y to configure the Torque Reference.
Press ENTER. You can connect the Torque Reference to any ONE of the following: the
HIM pot, Analog In1, Analog In2, the 4 – 20 mA input, or the gateway. Depending on which
input you choose, you may be prompted for an offset and scale value.
Step 6
If no, press ENTER.
6.
Configure Analog
Outputs? N
Press INC or DEC to toggle the N to a Y to connect the analog outputs. Press ENTER. Step 7
If no, press ENTER. Step 11
7.
Configure Analog
Output #1? N
Press INC or DEC to toggle the N to a Y to configure Analog Output 1. Press ENTER. You
can connect it to one of the following: Speed, Current, Volts, Torque, or Power. In addition,
you are asked for an offset and scale value.
Step 8
If no, press ENTER.
8.
Configure Analog
Output #2? N
Press INC or DEC to toggle the N to a Y to configure Analog Output 2. Press ENTER. You
can connect it to one of the following: Power, Speed, Current, Volts, or Torque. In addition,
you are asked for an offset and scale value.
Step 9
If no, press ENTER.
9.
Setup the 4 – 20 mA
Output? N
Press INC or DEC to toggle the N to a Y to configure the 4 – 20 mA output. press ENTER.
Step 10
If no, press ENTER.
10.
Configure HIM
Status Display? N
Press INC or DEC to toggle the N to a Y to adjust to output to the HIM display. Press
ENTER. You can link to Speed, Current, Volts, Torque, or Power. You are then asked to
reset the HIM.
Step 11
If no, press ENTER.
11.
Startup Complete
Press ENTER
Press ENTER.
