Starting Up Your System 6-3
Applying Power to Your Drive When the pre-power checks are completed, apply incoming power.
System design determines how you apply power. Make sure that you
know the safety controls associated with your system before applying
power. Only apply power if you thoroughly understand the 1336
IMPACT drive and the associated system design.
Measure the incoming line voltage between L1 & L2, L2 & L3, and
L1 & L3. Use a Digital Multimeter (DMM) on AC volts, highest
range (1000V AC). The input voltage should equal the drive rated
input voltage present on the drive’s nameplate within ±10%. If the
voltage is out of tolerance, verify that the drive rating is correct for the
application. If it is correct, adjust the incoming line voltage to within
±10%. Refer to Appendix D, Derating Guidelines, for the drive
current derating requirements for voltages above nominal to +10%.
Recording Your Drive and
Motor Information
Record the following information. You will need this information for
the start up routine and for any future servicing, if needed.
Table 6.A
Drive and Motor Information
Drive Nameplate Data
Catalog Number: ___________________________________________
Serial Number: _____________________________________________
Series: ___________________________________________________
AC Input:____________ Volts: _______________Amps:____________
AC Output: __________ Volts: _______________Amps:____________
Horsepower Rating: _________________ kW:____________________
Motor Nameplate Data
Catalog Number: ___________________________________________
Serial Number: _____________________________________________
Series: ___________________________________________________
AC Input:____________ Volts: _______________Amps:____________
Horsepower Rating: _________________ kW:____________________
Poles: ________________________ (May be located on the nameplate.)
RPM: ________________________
Hz: __________________________
Encoder Nameplate Data
Optional
Catalog Number: ___________________________________________
Serial Number: _____________________________________________
Series: ___________________________________________________
Input Power Supply: _____________________________________ Volts
Input Signal Level: ______________________________________ Volts
Output Signal Level: _____________________________________ Volts
Output Type: _______________________________________________
Pulse Per Revolution: _____________________________________PPR
Maximum Speed: ___________________________________________
Maximum Frequency: ________________________________________
Revision Levels
Main Control Board: _________________________________________
Gate Driver Board: __________________________________________
Jumper Settings
(Board Dependent)
____________________________ ___________________________
____________________________ ___________________________
