Owner's Manual

Contents
• (2) TMS69 Speakers
• (1) Main Harness
• (2) Speaker Grilles • (2 ) Saddlebag Harnesses
• (2) Mounting Rings • Plastic Wire Tie Wraps
• (2) Cutting Templates
•
Plasti c Cable T ie Mounts
•
(16) Mounting Screws
Installation Tools
The following is a list of suggested tools needed for installation:
• Drill • Small
Flat Blade Scr ewdriver
• Jigsaw
I Air sa w
• Phillips
Sc rewdriver
• 1/
8" Dri II Bit
•
Torx Drivers
• 5/ 16" Drill Bit
• Socket
set
• 3/4" Hole Saw
• Masking Tape
• Wire Cutters
Installation Considerations
This section focuses on some considerations for installing your Harle y-
Davidson® saddlebag lid speaker kit.
If y
ou feel unsure about installing this system yo urself, have it installed
by a qualified technician.
Wh en drilling hol es, make sure wh at is on the other s id e. Be sure that
any ele ctri ca l, fuel lines or any other importa nt compo nen ts ar e fre e
and cl e arf rom the area.
~WARNING
A CAUTION
A CAUTION
Before in stallation, dis conn ect the battery
negative(-) terminal to prevent damage to
the unit, fire and/or p
os sible injury.
Before beginning an y installation, follow
th
ese simple rul es:
Be sure to ca refully r ea d and und ersta nd
the in structions befo re atte mp t in g to in stall
th
ese spea ker kit s.
• Consult your motorcycles's service manual for model specific
information.
Model s may differ from year to y ea r depending on
factory options a nd afte rm a rk et access ori es a dd e d.
• Thi s sp ea k er kit is sp ec ifi ca lly des igned to wo rk wi th Roc kf o rd
Fo sga te's Pun ch® and Power s erie s co mpa ct amplifiers.
•
With the addition of an amplifier or so urce unit, be sure th at yo ur
current charging
sys tem is in proper working order.
• Vi sit rockfordfosgate.com for mo re comprehens ive product
informatio
n.
• Vi sit o urYouTube cha nn el for co mprehen si ve in stallation vid eos
demonstrating co mplete in stallation g uid es a nd in stall tips.
NEED HELP WITH YOUR INSTALLATION?
-@
VISIT OUR CHANNEL FOR A COMPLETE
......... YOUTUBE INSTALLATION VIDEO AND OTHER TIPS
........ WWW.YOunJBE.COMIUSERIROCKFORDFOSGATE
Installation
Applicable Models:
2014+ Harley-Davidson~~> Motorcycles with Factory Saddlebags
This saddlebag lid speaker kit is d es i gned to work with Rockford
Fosgate's co mpact chassis Pun ch® and Power series amplifiers.
Step 1. Rem ove the saddlebag lids, seat, gas tank and fairing cover
from the motorcycle.
Step 2. Us ing masking tape, tape over the painted porti on of your
saddlebag lids.
NOTE: This will prevent any scr at ch ing of the factory paint during the
installation
pro cess.
N OTE : Be sure the template sits snug on all sid es and corn ers of the
saddlebag lid before securing.
Screw Locations
Step 3. Ap p ly the templa te to the saddleb ag lid an d secu re using (2)
sc rews that ca me wi th the kit.
NO
TE: Th ere is a brake and clut ch s id e s pe cific template for each lid. Yo u
can use
an 1/8" drill bit to predrill ho les before screwing the template to
the lid.
Be sure the template is secur ed and wont move.
Step 4. Once the template is sec ur ed, u se a 5/16" drill bit a nd drill
holes
in the templa te .
NO
TE: We sug ge st drilling at e ve ry seg ment to make s aw i ng e as ier.
St ep 5. Usi ng a ji gsaw, fo llow along the templat e.
NOTE: DO NO T cut the segments of the templa te until all of the slots
have b
ee n cu t. Thi s will help ma in tain acc ura cy and fitment for th e
grilles.
N
OTE: Wh en cutt in g, be sure th at the sa w bla de st ays in betw ee n the
edges of the te mplate. Cutting in to t he template will l ead to fitment
i
ss u es .
