VS<arg>

Setsthespeedformovementofverticalservos.Allverticalservomovesusethisspeed.Valid
rangeis0to65535uS/Sec.
LF<arg>,LR<arg>

Setthevalueforthehorizontalservosontheleftsideoftherobot.LFsetsthefrontvalue,i.e.
thepulsewidthtomovethelegtothemaximumforwardposition;LRsetstherearvalue.The
validrangefortheargumentsis500to2500uS.

RF<arg>,RR<arg>

Setthevaluesforthehorizontalservosontherightsideoftherobot.RFsetsthefrontvalue,i.e.
thepulsewidthtomovethelegtothemaximumforwardposition;RRsetstherearvalue.The
validrangefortheargumentsis500to2500uS.

HT<arg>

Setsthetimetomovebetweenhorizontalfrontandrearpositions.Thevalidrangeforthe
argumentis1to65535uS.

XL<arg>,XR<arg>

Setthetravelpercentageforleftandrightlegs.Thevalidrangeis100%to100%.Negative
valuescausethelegsonthesidetomoveinreverse.Withavalueof100%,thelegswillmove
betweenthefrontandrearpositions.Lowervaluescausethetraveltobeproportionallyless,but
alwayscentered.ThespeedforhorizontalmovesisadjustedbasedontheXLandXR
commands,sothemovetimeremainsthesame.

XS<arg>

Setthehorizontalspeedpercentageforalllegs.Thevalidrangeis0%to200%.Withavalueof
100%,thehorizontaltraveltimewillbethevalueprogrammedusingtheHTcommand.Higher
valuesproportionallyreducethetraveltime;lowervaluesincreaseit.Avalueof0%willstopthe
robotinplace.ThehexsequencerwillnotbestarteduntiltheXScommandisreceived.


 
