Manual


LynxmotionSSC32UServoControllerBoard
ElectronicsGuide

Overview

TheLynxmotionSSC32UisaversatileandeasytouseR/Cservocontroller,thecoreofwhich
isanAtmelATmega328p.Featuresinclude:
● USB,serialorXBeeinput
● Controlupto32servomotors
● Builtin12DoFhexapodsequencer
● 8analoginputpins
● Easytounderstandcommandprotocol
● Advancedfeatures
● Idealforusewithrobotarmsorleggedrobots
● CompatiblewithFlowBoticsStudiographicalsoftware

NotethattheSSC32Uisadedicatedservocontroller;assuch,theboardisnotmeanttobe
“programmed”(orstorecodewhichausercreates)butinsteadsimplyreceivesandexecutes
commandssenttoitfromanexternaldevicesuchasacomputerormicrocontroller.Usinga
dedicatedservocontrollerfreesupmemoryonamicrocontrollerwhichwouldbeusedto
constantlyupdatetheservos’positions.

TheSSC32UisbasedlargelyontheSSC32.TheuserguidefortheSSC32canbefound
hereforreference:http://www.lynxmotion.com/images/html/build136.htm
