AnymovethatinvolvesmorethanoneservoanduseseithertheSorTmodifierisconsidereda
GroupMove,andallservoswillstartandstopmovingatthesametime.Ifyourequiremoving
severalservosatdifferentspeeds,youmustissuethecommandsseparately.
SoftwarePositionOffset.
Servo Position Offset

#<ch>PO<offsetvalue>...#<ch>PO<offsetvalue>...<cr>

● <ch>:channelnumberindecimal(0to31)
● <positionoffset>:thepositionoffsetisrestrictedto100usto100us(around15°)
● <cr>:carriagereturn

Thepositionoffsetcommandallowsyoutochangethecenterposition(associatedwith1500us)
ofoneormoreservosviasoftwarewithin15degreesoftheabsolutecenter.Theoffset
commandonlyneedstobesentoncetotheSSC32Uservocontrolleratthestartofthe
program.HoweverwhentheSSC32UisturnedoffitwillforgetthePositionOffsets.Notethat
theservoitselfisunchanged;itisonlythesignalsenttothatparticularpin(s)ontheSSC32
whichwillbealtered.

Onemajorusesofthisfunctionistocenter/alignaservo’spositionperfectlywiththe
mechanicstowhichitisconnected.Forexamplewhenassemblingaservotoabracketsystem,
youmaynoticethattheservoismisalignedbyafewdegreeswithrespecttotheframe,
whereasyourcoderequiresthatitbeperfectlyaligned.Althoughcorrectingthisissue
mechanicallyisverydifficult,thepositionoffsetcommandallowsforfineadjustment.It'sstill
importanttobuildthemechanicalassemblyascloseaspossibletothedesiredcentered
positionbeforeapplyingtheservooffset.
