LynxmotionSSC32UServoControllerBoard
ElectronicsGuide
TTL UART (TX / RX / G Pins)
CommandscanbesenttotheSSC32usingtheserialpinsontheboard.Therearetwoways
theBotBoarduinocanbeconnectedtotheSSC32
1.Directserialconnection
● TXfromtheBotBoarduinotoRXontheSSC32U
● RXfromtheBotBoarduinotoTXontheSSC32U
● GNDontheBotBoarduinotoGNDontheSSC32U
2.SoftwareSerial(allowingyoutoconnectotherdevicestotheBotBoarduino’sserialpins).
● I/Opin13ontheBotBoarduinotoSSC32TX(yellow)
● I/Opin12ontheBotBoarduinotoSSC32RX(red)
● GNDontheBotBoarduinotoGNDonSSC32(black)
SSC32UtoBotBoarduino/Arduino
