LynxmotionSSC32UServoControllerBoard
ElectronicsGuide

VS1=VS2Jumpers
Thesecondhalfofservopinsnumbered1631canbepoweredusingthesamepowersource
asVS1byleavingthetwoVS1=VS2jumpersinplace.Therearetwojumpers(ratherthanjust
one)becauseofthecurrentinvolved.Shouldyouwanttopowerthelineofservosconnectedto
VS2separatelyfromVS1,youcanremovethesetwojumpers.IfyouhavethetwoVS1=VS2
terminalsinplace,youcanpowerEITHERVS1orVS2,butnotboth.Examplesofwhen
removingthesejumpersisbeneficialinclude:
● Asecondbatteryisneededbecauseofhighcurrent
● Secondsetofservosoperateatadifferentvoltage
● Wanttousetwoseparatepacksforpower

VL=VS
ThejumperVL=VSisawayofforcingthelogicvoltagetousethepowerconnectedtoVS1.
Unlessyouarehavingunusualproblemswiththeautopowerselect,thisjumpershouldnotbe
used.Thisjumperisnotinstallednorincludedinthepackage.DonotusetheVLscrew
terminalsifyouinstallthisjumper.

