RSSI

RSSIstandsfor“ReceivedSignalStrengthIndication”andtheLEDisconnectedtopin6ofthe
Xbeesocket.Differentblinkintervalsareusedtoindicatedifferentstatusbasedonthemodule
chosen.

PWR

ThePWRLEDisconnectedtoV_logicwhichistheequivalentofMAX(VL,VS1)minusroughly
0.7V.It'sthevoltagethat'sthenregulatedto5Vforpoweringthelogiccircuits.TheLEDislit
whenthemicrocontrolleronboardreceivesadequatepower.
