Manual


LynxmotionSSC32UServoControllerBoard
ElectronicsGuide

A/BLEDs

TherearetwodistinctLEDsontheboardlabeledAandBWhennotsettingtheBaudrate,the
LEDsindicatethefollowing:
● BothONatpowerupbeforeabyteisreceived.
● Greenflasheswhenavalidbyteisreceived.
● Redflasheswhenaninvalidbyteisreceived(framingerror).
Formoreinformation,pleaserefertotheBaudsectioninthisguide.

5GPins

Thesepinsarenormallynotneeded,andpinsarenotprovided.Shouldthetwocapacitors
onboardnotbesufficientforyourapplication,athirdcapacitorcanbeaddedhere.Ifyouarenot
wellversedinelectronics,wesuggestnottouchingthispartoftheboard.


13
