Manual


LynxmotionSSC32UServoControllerBoard
ElectronicsGuide

TxRx

ThetwoLEDsnexttotheUSBportprovidetheuserwithvisualfeedbackofwhendatais
received(Rx)andifdataistransmitted(Tx).Theseareonlyassociatedwithcommunicationvia
theUSBportandnottheXBeeheaderorserialpins.

Serial

ThethreepinsbehindtheFTDIchipareTx,RxandGND.CommandssentfromtheSSC32U
aredoneusingtheTxpinwhilecommandstobereceivedbytheSSC32UaredoneviatheRx
pin.Thesepinsallowyoutoeasilysendcommandstotheservocontrollerfromanother
microcontroller.Todoso,connecttheTxpinonthemicrocontrollertotheRxpinonthe
SSC32U,theRxpinonthemicrocontrollertotheTxpinontheSSC32andGNDtoGND.




 
12
