XBee

TheXBeeheadersallowyoutoconnectanXBeewirelessmoduleotherXBeecompatible
devices.Takenoteoftheimageontheboardforhowtoorientthemodule.Pleaserefertothe
communication/controlsectioninthisguideformoreinformation.

USB

CommandscanbesenttotheSSC32U’smicroprocessorfromthecomputerviatheonboard
USBport.Themicroprocessorcanonlyunderstandcommandssentinserial(notUSB)format,
soanFTDIchip(theareahighlightednexttotheUSBport)convertstheUSBdatastreamto
serialandallowstheboardtobepickedupbyyourcomputer’sCOMportonceconnected.
Pleaserefertothedriverssectionbelowformoreinformation.




