Manual


LynxmotionSSC32UServoControllerBoard
ElectronicsGuide


VS=VL

ThesetwopinsallowyoutotietheVS1terminaltoVL(i.e.VL=VS).Thiswouldhavethesame
effectasrunningawirefromfromtheVS1+screwterminaltotheVL+screwterminal.
Pleaserefertothepowersectionofthisguideforimportantinformation.Ajumperforthesepins
isnotincluded.

VS1=VS2

These2x2pinsallowyoutosetVS1=VS2.Thiswouldhavethesameeffectasrunningawire
fromtheVS1+screwterminaltotheVS2+screwterminal.Therearetwojumperstohandle
highercurrent.Theboardisshippedwiththeseinplaceanditisuptotheusertoremovethem
ifneeded.Pleaserefertothepowersectionofthisguideforimportantinformation.


 
