Battery
Press GO
Battery voltage
12.8 25.5 12.7
Last run times
Press GO
1) 2h34m 25.8V
25/05/08
2) 2h32m 25.7V
24/05/08
10) 2h27m 25.7V
18/05/08
Battery
Press GO
Battery
Press GO
Battery
Press GO
Battery voltage
12.8 25.5 12.7
Last run times
Press GO
Last run times
Press GO
Last run times
Press GO
1) 2h34m 25.8V
25/05/08
2) 2h32m 25.7V
24/05/08
10) 2h27m 25.7V
18/05/08
1) 2h34m 25.8V
25/05/08
2) 2h32m 25.7V
24/05/08
10) 2h27m 25.7V
18/05/08
Figure 2.13
Battery menu
Temperatures
Press GO
Drive temp.
Press GO
Mow temp.
+24 C +75 F
Main board
+35 C +95 F
Left drive
+26 C +78 F
Right drive
+26 C +78 F
Temperatures
Press GO
Temperatures
Press GO
Temperatures
Press GO
Drive temp.
Press GO
Mow temp.
+24 C +75 F
Main board
+35 C +95 F
Left drive
+26 C +78 F
Right drive
+26 C +78 F
Figure 2.14
Temperatures menu
Figure 2.15
Configuration menu
Figure 2.16
Last stop causes menu
Configuration
Press GO
Main board
ESB5000E
Software
5.4v 21/10/07
Base
ESB5002C v1.27
Configuration
Press GO
Configuration
Press GO
Configuration
Press GO
Main board
ESB5000E
Software
5.4v 21/10/07
Base
ESB5002C v1.27
Last stop causes
Press GO
1) 11 [ 3]
10:35 25/05/08
2) 20 [ 2]
11:24 24/05/08
10) 7 [ 6]
10:58 19/04/08
Last stop causes
Press GO
Last stop causes
Press GO
Last stop causes
Press GO
1) 11 [ 3]
10:35 25/05/08
2) 20 [ 2]
11:24 24/05/08
10) 7 [ 6]
10:58 19/04/08
2.3.2 Battery
Battery voltage – Displays the current voltage of the batteries.
Last run times
– Indicates the last battery run time in the last 10 operations, the voltage at the
beginning of the operation and the operation date.
2.3.3 Temperatures
Displays the temperatures on the drive motors, mowing motor and on the Main Board.
2.3.4 Configuration
Displays the configuration of the Robomow: Main Board part number, software version and Base
Station Board part number (figure 2.20):
2.3.5 Last stop causes
Displays the last ten stop causes number and the date of the stop.
