Operation Manual

EN
32
Operation
Press GO
Total time
253h47m
First operation
Date: 13/03/08
Operation
Press GO
Operation
Press GO
Operation
Press GO
Total time
253h47m
Total time
253h47m
Total time
253h47m
First operation
Date: 13/03/08
First operation
Date: 13/03/08
First operation
Date: 13/03/08
Figure 2.12
Operation menu
Figure 2.9
Eco mode menu
2.2.5 Language
Allows the user the option of viewing the LCD text in several different language versions.
2.2.6 ECO Mode
The ECO (Economic) mode feature enables operating Robomow using minimum energy
required to cut the grass and maintain the lawn. The ECO mode default is set to 'on'.
Operation in ECO mode reduces Robomow noise level during operation and allows longer
operation time. It is recommended to use the ECO mode only in zones with Base Station,
where mowing is more frequent and a shorter part of the grass is cut. If Robomow detects
high grass it will automatically increase the power of the mowing motor to enable cutting
higher grass
.
2.2.7 Signal type
In some circumstances there may be interference to the wire signal caused by other wire signal
activated in adjacent lawn (neighbor that use robotic lawnmower) or by any other appliance
using similar frequency. In case of signal interference, you may see one of the following
symptoms (usually close to the neighbor lawn):
a. Robomow is widely swinging when driving along the wire;
b. Robomow changes direction without reaching the wire;
c. Robomow crosses the wire outside the designated area;
d. 'Start inside' message is displayed although Robomow is inside the designated area and
the perimeter wire is connected in the right polarity;
If your mower faced one of the above symptoms, to change the signal type call to service
2.2.8 Wire Position
Allows user to test the wire position in ‘Edge’ mode while the mowing motors are switched off to
prevent any damage to the perimeter wire after the initial setup of the wire is completed.
2.2.9 Delay operation
This option allows the user to press GO but delay the operation starting time. It is useful when you
want to start the operation later in the day when the grass is dry and not early in the morning
when the grass is wet (and you have to leave for work).
To use this option, follow the steps below:
- Set the ‘Delay operation’ to X hours (choose between 1,2,3…or up to 8 hours);
- Switch on the Perimeter Switch (It is operated for 12 hours) and place the mower inside the
lawn towards the perimeter wire;
- Pressing ‘STOP’ then ‘GO’ (while holding the ‘STOP’ button) will change the display to ‘Press
GO again to skip edge’ and at the end of the warming up process, the mower will stay in place
with a message ‘Operation delayed – wait…’
- The mower will start the operation after X hours (as set in the ‘Delay operation’ menu) from the
‘GO’ pressing.
2.3 Information
The ‘Information’ display (refer to figure 2.1) is used for information only, it allows the option to
scroll between the following menus:
2.3.1 Operation
Total time - Indicates the total number of hours the mower has been in operation.
First operation
– Indicates the date, in which the mower was first operated.
Eco mode
Press GO
Eco mode on
Press GO
Eco mode of
f
Confirm
