Specifications
32
Weight (net):
21.7 kg
Dimensions (mm)
Accessories
Omega holder (No.99010420)................................2 pcs
Gobo-set 16 (No. 15050025) ................................ 1 piece
Optional Accessories
- Flash cable RS232/DMX (No.13050624)
12. Maintenance and cleaning
It is absolutely essential that the xture is kept clean and that dust, dirt and smoke-uid residues must not build
up on or within the xture. Otherwise, the xture‘s light-output will be signicantly reduced. Regular cleaning will
not only ensure the maximum light-output, but will also allow the xture to function reliably throughout its life.
A soft lint-free cloth moistened with any good glass cleaning uid is recommended, under no circumstances
should alcohol or solvents be used!
DANGER !
Disconnect from the mains before starting any
maintenance work
The front objective lens will require weekly cleaning as smoke-uid tends to building up residues, reducing
the light-output very quickly. The cooling-fans should be cleaned monthly.
The interior of the xture should be cleaned at least annually using a vacuum-cleaner or an air-jet.
Dichroic colour lters, CMY lamellas, gobo wheels and the internal lenses should be cleaned monthly.
Remove dust and dirt from the fans and cooling vents using a soft brush and vacuum-cleaner.
Important! Check the air lters periodically and clean before they become
clogged!
Clean the air lters placed in the xture´s covers. Use a vacuum cleaner, compressed air or you can wash
them and put back dry.
After replacing the air lters, reset the elapsed time counter in the menu "Information" (Information--->Air Fil-
ters---> Elapsed Time).
