to escape from this menu.
We recommend to cancel all running programs before starting the Software Uploader.
3. Run the Software Uploader program. Select desired COM and then click on the Connect button.
(Select COM if the serial port is used or DreamBox1 if the USB port is used).
If the connection is OK, click on the “Start Uploading button“ to start uploading. It will take several
minutes to perform software update.
If the option "Incremental Update" is not checked, all processors will be updated (including
processors with the same software version).
If you wish to update only later versions of processors, check the “Incremental Update box“.
Avoid interrupting the process. Update status is being displayed in the Info Box window.
When the update is nished, the line with the text “The xture is successfully updated“ will appear in
this window and the xture will reset with the new software.
Note: In the case of an interruption of the upload process (e.g. power cut), the xture keeps the updating mode
and you have to repeat the software update again.
7.7 Icon "Lamp menu"
Lamp Status - The item enables to switch the lamp on/off. The MSR Gold 575/2 MiniFastFit lamp is a cold
restrike type, that means, that it has to be cold before striking.
Settings - The menu offers many items for setting of lamp behaviour.
Lamp Ignition Delay - The item allows to set the time delay( 0-90sec.) before igniting the lamp by DMX
command. If the lamp is started directly from the control panel, the time delay will be ignored.
Lamp Light Sensor - Select this item to switch the light sensor off. The option "On” is intended for a standard
operation. The option "Off” is for “emergency operation” only! If the lamp light sensor is switched off, the xture
will still try to ignite the lamp (even when the lamp is damaged or absent), on this account some electronics
parts of the xture can be damaged!
Lamp On/Off Settings - Use the menu to set rules for automatic switching on/off the lamp.
Lamp On Power On - If the item is on, the lamp will be automatically turn on after switching the
xture on.
Lamp Off via DMX - The item enables to switch the lamp off via DMX command from DMX
controller.
Lamp On if DMX Present - The item allows you to strike the lamp automatically after 26 seconds
if DMX signal is present on the xture´s DMX input.
Lamp Off if not DMX - The item allows you to switch off the lamp automatically after 2 minutes
if DMX signal is missing on the xture´s DMX input.
8. RDM
This xture supports RDM operation. RDM (Remote Device Management) is a bi-directional communications
protocol for use in DMX512 control systems, it is the new open standard for DMX512 device conguration and
status monitoring.
The RDM protocol allows data packets to be inserted into a DMX512 data stream without adversely affecting
existing non-RDM equipment. By using a special „Start Code,“ and by complying with the timing specications
for DMX512, the RDM protocol allows a console or dedicated RDM controller to send commands to and receive
messages from specic moving lights.
RDM allows explicit commands to be sent to a device and responses to be received from it.
The list of commands for Robin 600ESpot is the following.
Parameter ID Discovery command SET command GET command
DISC_UNIQUE_BRANCH *
DISC_MUTE *
DISC_UN_MUTE *
DEVICE_INFO *
SUPPORTED_PARAMETERS *
SOFTWARE_VERSION_LABEL *
