Date & Time Settings - Use this menu to set current date and time for the xture log system (menu "View

Logs"). Set this menu item before rst xture operation.

Unlink Wireless Adapter - The menu serves for unlinking the xture from the transmitter (only WDMX ver-

sion)

Default Settings - The menu item allows to set all xture parameters to the default (factory) values.

7.4 Tab "Manual Control"

Reset Functions - The menu allows to reset the xture either per function modules or all modules together.

Total Reset - The item resets all function modules.

Pan/Tilt Reset - The item resets a pan and tilt movement.

Colour System Reset - The item resets a colour wheel and CMY/CTO ags.

Gobo System Reset - The item resets a static/rotating gobo wheel.

Strobe/Hot-Spot Reset - The item resets strobe lamellas and a hot-spot module.

Optics/Prism/Frost Res. - The item resets a zoom, focus, prism and a frost module.

Iris Reset - The item resets an iris module.

Preset Effect Control - Use the menu to show preset positions of each channel effect.

Manual Effect control - Use the menu to control all xture channels by means of the control panel.

7.5 Tab "Stand-alone"

Test Sequences -Use the menu to run a test/demo sequences without an external controller, which will show

you some possibilities of using Robin 600ESpot.

Dynamic Mode - This mode uses all Robin 600ESpot functions including pan/tilt movement and therefore

is good for a complete introduction of the xture.

Static Mode - This mode is suitable for projections on the wall, ceiling or ground without any pan/tilt move-

ment. Adjust the pan, tilt, zoom, focus and hot-spot to desired positions an start test sequences by touching

the green icon.

Music Trigger - Use the item to activate the sound control of the running program via the built-in micro-

phone.

Preset Playback - This menu allows you to select the program which will be played in a loop after switching

the xture on (the option is commonly used in a stand-alone operation without an external controller).

None - The option disables “Presetting playback” function.

Test - The option starts the test sequences.

Prog. 1 - The option starts user program No. 1.

Prog. 2 - The option starts user program No. 2.

Prog. 3 - The option starts user program No. 3.

Play program - Use the menu to run desired program in a loop.

Play Program 1 - The option starts user program No.1.

Play Program 2 - The option starts user program No. 2.

Play Program 3 - The option starts user program No. 3.

Edit Program - Use the menu to create or to edit desired program. The Robin 600ESpot offers 3 free programs,

each up to 100 steps.

Edit Program 1 - The option allows to edit user program No.1.

Edit Program 2 - The option allows to edit user program No.2.

Edit Program 3 - The option allows to edit user program No.3
