Specifications

22
Software Version - Select this item to read the software version of the xture modules:
Display System - A display processor on the display board in the xture base
Module M - A pan/Tilt processor on the main board in the xture arm
Module S - A strobe/colour/hot-spot processor on the board in the xture head.
Module I - A rot. gobo/stat. gobo/iris processor on the board in the xture head.
Module O - A focus/zoom/prism/frost/ processor on the board in the xture head.
Module C - CMY+CTO processor on the board in the xture head.
Product IDs - The menu is used to read the MAC Address ,RDM UID and RDM Label.
View Logs - Use this menu to read xture´s data which have been recorded during xture operation. This
colected data allows easier troubleshooting.
Fixture Errors - Use this menu to read xture errors which have occured during xture operation.
There is a list of error folders:
Pan Errors Prism Errors
Tilt Errors Prism Rotation Errors
Dimmer 1 Errors Frost Errors
Dimmer 2 Errors Cyan Errors
Colour Errors Magenta Errors
HotSpot Errors Yellow Errors
Gobo Errors CTO Errors
Gobo Carousel Errors Clean Air Filters
Static Gobo Errors Lamp is Too Hot
Iris Errors Overheated
Focus Errors Active Lamp Timer
Zoom Errors Lamp Errors
Temp. Sensor Errors
Fixture States - Recorded following actions: Fixture On, Fixture Off, Lamp On, Lamp Off.
Fixture Position - Recorded installation positions of the xture:
Fixture Temperatures - Recorded temperatures which have exceeded dened levels.
Note: The log buffer can contain 8000 records max. If the buffer is full, old data will be overwritten.
7.3 Tab "Personality"
User mode - The Robin 600ESpot allows you to recall up to 3 user settings. After switching the xture on for
the rst time, the User A settings is active. Now all changes made in the “Personality” menu , ”Addressing”
menu and the “Music Trigger“ and Preset Playback“ items from the “Stand-alone” menu are saved to the
User A settings. If you now select the User B settings, from this moment the changes made in these menus will
be saved to the User B settings. After switching the xture off and on, the User B setting is active. In this way
you may use the 3 xture operating behaviours.
User A Settings - the function recalls the user A settings.
User B Settings - the function recalls the user B settings.
User C Settings - the function recalls the user C settings.
DMX Preset - Use the menu to select desired channel mode.
Mode 1 - 32 control channels
Mode 2 - 25 control channels
Mode 3 - 23 control channels
View Selected Preset - Use the menu to display channels included in the selected mode.
