Robin 600E Spot Table of contents 1. Safety instructions.......................................................................................................... 3 2. Operating determination................................................................................................. 4 3. Fixture exterior view ...................................................................................................... 5 4. Installation............................................................................
CAUTION! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOU INITIAL START - UP! 1. Safety instructions Every person involved with installation and maintenance of this device have to: - be qualified - follow the instructions of this manual CAUTION! Be careful with your operations.
2. Operating determination This device is a moving head for creating decorative effects and was designed for indoor use only. If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature. Never run the device without lamp! Do not shake the device. Avoid brute force when installing or operating the device.
3. Fixture exterior view 1 - Front lens 2 - Tilt lock 3 - Pan lock 4 - Base 5 - Moving head 6 - Arm The head should be locked for transportation- the tilt lock latch (2) and the pan lock latch (3) have to be in the locked positions. To unlock the head, move these latches to unlock positions before operating the fixture.
4. Installation Fixtures must be installed by a Qualified electrician in accordance with all national and local electrical and construction codes and regulation. 4.1 Connection to the mains For protection from electric shock, the fixture must be earthed! The Robin 600E Spot is equipped with auto-switching power supply that automatically adjusts to any 50/60Hz AC power source from 100-240 Volts.
4.2 Installing the lamp DANGER ! Install the lamp with the device switched off only. Unplug from mains before ! To insert the new lamp. 1. Disconnect the fixture from power and allow it to cool at least 15 minutes. 2. Make sure that the fixture´s head is in the position as shown on the picture (notices on the lamp cover are in readable position) .Loosen the two quarter-turn fasteners (1) marked “X,Y“ on the lamp cover to open this cover. 3.
4.4 Replacing the colour filters and gobos DANGER! Install the colour filters or gobos with the device switched off only. Unplug from mains before! Colour filters 1. Disconnect the fixture from mains and allow it to cool. 2. Remove the top plastic cover of the head by loosening the 4 quarter-turn fasteners on the cover. 3. Turn the colour wheel to the desired position.The dichroic filters are fixed on the colour wheel by the magnets. 4.
Rotating gobos 1. Disconnect the fixture from mains and allow it to cool. 2. Remove the bottom plastic cover of the head by loosening the 4 quarter-turn fasteners on the cover. 3. Gently pull up the gobo holder from the rotation gobo wheel. 4. Remove the spring gobo-lock with an appropriate tool (e.g. small-bladed screwdriver) and remove it. Do not touch the surface of the pattern of the glass gobo. 5. Remove the original gobo and insert the new one (glazy side towards the lamp).
4.5 Rigging the fixture The installation of the fixture has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation. The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net. This secondary safety attachment must be constructed in a way that no part of the installation can fall down if the main attachment fails.
Truss installation 1.Bolt each clamp (1) to the omega holder (3) with M12 bolt and lock nut through the hole in the holder. 2.Fasten the omega holders on the bottom of the base by inserting both quick-lock fasteners (4) into the holes of the base and tighten fully clockwise. 3. Pull the safety wire (2) through the carrying handles (5) and around the truss (6) as shown on the pictures below.
4.6 DMX-512 connection The fixture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired in parallel. Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in order to connect the controller with the fixture or one fixture with another.
4.7 Ethernet connection The fixtures on a data link are connected to the Ethernet with ArtNet communication protocol.The control software running on your PC (or light console) has to support Art-Net protocol. Art-Net communication protocol is a 10 Base T Ethernet protocol based on the TCP/IP.Its purpose is to allow transfer of large amounts of DMX 512 data over a wide area using standard network technology. IP address is the Internet protocol address.
Ethernet / DMX operation Options “Art2DMX” has to be selected from the “Ethernet Mode” menu on the first fixture (connected to the Ethernet) in the fixture chain,next fixtures have standard DMX setting. Connect the Ethernet-input of the first fixture in the data chain with the network. Connect the DMX output of this fixture with the input of the next fixture until all fixtures are connected to the DMX chain. Caution: At the last fixture, the DMX chain has to be terminated with a terminator.
5. Remotely controllable functions Lamp The Robin 600ESpot is to be operated with a Philips MSR Gold 575/2 MiniFastFit . Note: It is also important to note, that the discharge lamp is cold restrike types, that means, that they have to be cold before re-striking. For this reason, you have to wait 5 minutes after having switched the lamp off before you can switch it on again.
6.
Tab Level 1 Level 2 Level 3 Level 4 Base Temperatures Personality User Mode User A Settings User B Settings User C Settings DMX Presets Mode 1 Mode 2 Mode 3 View Selected Preset Pan/Tilt Settings Pan Reverse Off, On Tilt Reverse Off, On Pan/Tilt Feedback Off, On Pan/Tilt mode Time Speed Microphone Sensitivity 1-10-20 Blackout Settings Blackout During M.C.
Tab Level 1 Level 2 Stand -Alone Test Sequences Dynamic Mode Static Mode MusicTrigger Off, On Preset Playback None Level 3 Level 4 Level 5 Level 6 Pan 0-255 Tilt 0-255 Zoom 0-255 Focus 0-255 HotSpot 0-255 Start Step 1-100 End Step 1-100 Edit Program Steps Step 1 Pan 0-255 : : : Dimmer Fine 0-255 : Step Time 0-25,5 sec. Step 100 Pan 0-255 Test Prg. 1 Prg. 2 Prg.
7. Control menu The Robin 600ESpot Light is equipped with the QVGA Robe touch screen with battery backup which allows to set the fixture´s behaviour according to your needs, obtain information on its operation, test its various parts and lastly program it, if it has to be used in a stand-alone mode. The fixture´s menu can be controlled either by the control buttons or directly by touching the icon. Control buttons on the front panel: [ESCAPE] button used to leave the menu without saving changes.
Touch any part of the screen or press the [ENTER/Display On] button to display the initial screen with the current stored DMX address: Touch the green arrow at the bottom right corner of the screen or press the [ENTER/Display On] button to enter the " Address" menu. An item (such as a Tab, menu item, text box, icon) may be selected from a screen by simply touching the item in the list or by pressing the [NEXT] or [PREV] buttons to scroll through list items. With each press, the next item is highlighted.
Fixture Times - The menu provides readouts of fixture and lamp operation hours. Power On Time Hours - Select this menu to read the number of fixture operation hours. Total Hours - The item shows the total number of the operation hours since the Robin 600ESpot has been fabricated. Resetable Hours - The item shows the number of the operation hours that the Robin 600ESpot has been powered on since the counter was last reset.
Software Version - Select this item to read the software version of the fixture modules: Display System - A display processor on the display board in the fixture base Module M - A pan/Tilt processor on the main board in the fixture arm Module S - A strobe/colour/hot-spot processor on the board in the fixture head. Module I - A rot. gobo/stat. gobo/iris processor on the board in the fixture head. Module O - A focus/zoom/prism/frost/ processor on the board in the fixture head.
Pan/Tilt Settings - Use the menu set behaviour of both pan and tilt movements. Pan Reverse - The item allows to invert pan movement. Tilt Reverse - The item allows to invert tilt movement. Pan/Tilt Feedback - The item allows to return the mowing head to the required pan/tilt position after changing the position by an external force if this option is set on. Note.
Date & Time Settings - Use this menu to set current date and time for the fixture log system (menu "View Logs"). Set this menu item before first fixture operation. Unlink Wireless Adapter - The menu serves for unlinking the fixture from the transmitter (only WDMX version) Default Settings - The menu item allows to set all fixture parameters to the default (factory) values. 7.4 Tab "Manual Control" Reset Functions - The menu allows to reset the fixture either per function modules or all modules together.
To edit program: 1. Touch the item which you want to edit (“Edit Program 1” - “Edit Program 3”). 2. Touch the item "Edit Program Steps". 3. Touch the item "Step 1". 4 From the list of effects touch desired effect and set its value. Browse throw the list by touching the [up arrow] and [down arrow] and set all desired effects. An item "Step Time" (value of 0-25.5 sec.) is the time during which effects last in the current step 5.
By using these items you can calibrate and adjust effects to their right positions. Calibration via the control board 1. Disconnect DMX controller from the fixture and enter the "Calibrate Effects" menu. 2. Use the [up arrow] and [down arrow] to find desired effect and touch it to enter the fine effect adjustment screen. 3. Set desired value and save it by touching the [confirm]. 4. Repeat steps 2 and 3 for the next effects. 5.
to escape from this menu. We recommend to cancel all running programs before starting the Software Uploader. 3. Run the Software Uploader program. Select desired COM and then click on the Connect button. (Select COM if the serial port is used or DreamBox1 if the USB port is used). If the connection is OK, click on the “Start Uploading button“ to start uploading. It will take several minutes to perform software update.
Parameter ID Discovery command SET command GET command DMX_START_ADDRESS * * IDENTIFY_DEVICE * * DEVICE_MODEL_DESCRIPTION * MANUFACTURER_LABEL * * DEVICE_LABEL * * SENSOR_DEFINITION * SENSOR_VALUE DISPLAY_INVERT * * DISPLAY_LEVEL * * PAN_INVERT * * TILT_INVERT * * DEVICE_RESET * DMX_PERSONALITY * * DMX_PERSONALITY_DESCRIPTION * STATUS_MESSAGES * STATUS_ID_DESCRIPTION * LAMP_STATE LAMP_ON_MODE DEVICE_HOURS LAMP_HOURS 1 * * * * * 2 * 2 LAMP_STRIKES * ...
store the attempt to ignite the lamp and automatically ignites the lamp when the 5 minutes period will expire. Lamp Error If the ignition of the lamp is 4 times unsuccessful (the “Active Lamp Timer” message appeared 3 times before), the display shows “Lamp Error”, meaning that the lamp could be damaged or even missed or there could be a failure on the igniter or ballast.
Gobo rotation Error 1 (Gobo Rotation Error 2 ) The messages will appear after the reset of the rotating gobo wheel if the rotating gobos are not located in the default positions. Static Gobo Error 1 (Static Gobo Wheel Error 2 ) The messages will appear after the reset of the static gobo wheel if this wheel is not located in the default position. Clean Air Filters The message informs that the item "Elapsed Time" in the "Fixture Information" menu is at 0 value. Clean air filters and reset this counter. 11.
Frost filter: Zoom Strobe: Separate,variable frost filter Linear motorized zoom: Strobe effect with variable speed (max.15 flashes/sec.) Electronic strobbing (max. 33 flashes/sec.
Weight (net): 21.7 kg Dimensions (mm) Accessories Omega holder (No.99010420)................................2 pcs Gobo-set 16 (No. 15050025) ................................ 1 piece Optional Accessories - Flash cable RS232/DMX (No.13050624) 12. Maintenance and cleaning It is absolutely essential that the fixture is kept clean and that dust, dirt and smoke-fluid residues must not build up on or within the fixture. Otherwise, the fixture‘s light-output will be significantly reduced.
Replacing the fuse. Before replacing the fuse, unplug mains lead. 1) Remove the fuse holder on the rear panel of the base with a fitting screwdriver from the housing (anti-clockwise). 2) Remove the old fuse from the fuse holder. 3) Install the new fuse in the fuse holder (only the same type and rating). 4) Replace the fuseholder in the housing and fix it. Specifications are subject to change without notice.
" # ( ! $$% & '() * + '() , - !" & ' # $ ! ! % " & ! % & ( ) ! !"#$"## % !& ' ( * ( * ! ! +( * ! ,( - # . /0 * ( ! # . /0 (( - # . /0 . /0 & ( ! # . /0 &&( - # . /0 $ /0 & ( ! # . /0 $ + , ( & && & &1 & & &+ &, & &( &1( & ( & ( &+( &,( & ( &(( ( & 1 2 5 6 8 9 ( ) 1( 2 3 4 ' $ * $ $ . /0 $ /0 " &+ 1 3 $ % * . /0 *'0. * .* *7 * ! 3 ! :' : ! ! + #$'&#,, ; ! 3 $ * + & ( ) */0 ! .
( ! '() , - + 6 2 $0 (+ < && => & & ( ?0 &1 &1 & + & &+ &, & &( &+ & &1, & & 1 &+1 &,& & & & ( & &, 1 ( ! ! . 3 $ 6 2 $0 ! < => / ! / @ - #/ ! / ) ! . "' 0 <. ! . ! . / / .! .A / & / $ 0 - . 5 $ " /0 . % ( / 0 $ $ 4 " /0 4 . $ 1 . C / " /0 4 . /% 2 0 " +( D4 1 D% (1 $ , & &+ 1 1& 1 1( , + +1 + ,& , ,( , ( (+ & 1 & &&& && &&( & & , & &1 &1+ & 1 & & & & & ( @ B% .
( ! '() , - &+ &+ &,+ & &( &+, &, & & 1 &(& 1 &(( , & + &+ 1 , 1& 1 1( ( 1 1 ( ) ! "' 0 <. ! .! .: E :% / % ' ' ) -.
( ! '() , &, & &( &,( & ( &(( & & 1 1 ( 6 6 6 3 , ( *0 / ! $ /0 @ - #/ ! $ ) ! $ / /0 / .! * <.
( ! '() , & & 1 1 ( 3 *0 / ! $ /0 @ - #/ ! $ /0 ) ! $ "' 0 <. ! $ " +/ # . / & 6 & @ / .! .A / 3 / !' !( !) ! $ !' !# !) & & , / ! $ & & ( @ &1 - #/ ! $ / / " +/ # 0 ! 3 / $" & % $ &( 3 & , 1 & & &1+ & & &+ &+ &,+ & &( "0 $ % *$ & &1 & 1 & & & ( &+, &, & 1 &(& &(( , & &+ 1 1& 1 1( , 1 + , ( & && & &1 & & &+ . @ & & , / ! & & ( @ &1 - #/ ! / / 0 3 & &,( & & ( & G &( && . & 11 . 1 ) $ $ .
( ! '() , - 3 & &,( & &(& 5 &( &( . , . ( ) & ) 1 ) ) 4 ! ! ! $ / $ ! ! ! ! / $" % $ " /% $" % $ " /% . . . . & 5 0 8 $ 5 & H $ $ 5 . . !I. & . . $ 6 & 0 - ! . ! $ 1& 1 +1 + ( (+ & , & & 1 & & ( &+ &(& &( 1 # '0. '0. ' '0. 3 $ . 5 $ . '0. ) ! '0. !4 2 4 . 42 / + ? / / / J. J. !. ! + ? / / 4E $ A8< B / 4 . / ' - ' -& G ! !.
