Datasheet

Table Of Contents

Ribbon Cable, PVC

Art. Nr.

RND 475-00804

Specification

Conductor Material

Stranded bare copper

Conductor Size 14/0.15AS±0.008mm*3PCS

Insulation Material 45P PVC

Pitch

1.4mm

Outer Diameter 1.4mm±0.05mm*4.2mm±0.15mm

Temperature

80℃

Min. Average Thickness 0.37mm±0.05mm

Roll 30M/Roll

Colour

Brown , Red , Orange

Voltage rating 300 V

Fire behaviour

UL 94 V2

Operating Temperature Min. 15 °C
