Operator`s manual

3 M2 Transmitter Operator’s Manual
WARNING: When using the M2, you must follow the instructions and warnings in
this manual to assure proper and safe operation of the M2 and to
minimize the risk of personal injury. Be sure to maintain and periodically
calibrate the M2 as described in this manual.
Sampling Method Diffusion
Input Power 19 - 30 VDC
Controls • Three push button switches
• Three magnetic switches for non-intrusive calibration
Weight 4.5 lbs.
Signal Output • 4 to 20 mA, 500 ohms impedance max
• RS-485 Modbus
Operating
Temperature
• ESM-01 Type: -10°C to 40 °C
• All Others: -20°C to 50°C
Accuracy ± 5% of full scale
*
These are the RKI factory settings. You can change the alarm settings in Configuration Mode. See
“Viewing & Changing M2 Parameters” on page 30.
Table 1: M2 Specifications
