59 M2 Transmitter Operator’s Manual
Register 40
Register 40 is the remote configuration register access level
0=None
1=Alarm Reset Only
2=All
Function Code 16: Write Registers
There are 21 registers in Function Code 16 that can be used to write to the M2. This
manual only describes Register 16 because it can be used to reset an alarm condition. For a
complete description of Function Code 16, request Appendix B from RKI Instruments, Inc.
Register 16
Register 16 performs the same functions as the buttons on the M2. Among other things, it
is useful for remotely silencing alarms. With the M2 in an alarm condition, bit [0] can be
used to silence it.
Table 14: Register 16, Button Function
NOTE: Register 40, the remote configuration register, must be set to 1 or 2 in order for
Register 16 to work.
Bit Value & Field
[0] ENTER (also used for “Alarm Reset”)
0=Not Pressed
1=Pressed
[1] DOWN/NO
0=Not Pressed
1=Pressed
[2] UP/YES
0=Not Pressed
1=Pressed
[3] HOLD Status
0=Button(s) Pressed and Released
1=Button(s) Pressed and Held
