Updating the target gas label
1. From the main menu, select the GAS COMBINATIONS menu option.
2. Press the POWER/ENTER button to display the Gas Combinations
menu.
3. Use the AIR/
or SHIFT/ button to place the prompt next to the toxic
gas channel (in this example H2S or CO).
4. Press the POWER/ENTER button. The toxic target gas label ashes. This
indicates that this setting can now be updated.
5. Press the AIR/
or SHIFT/ buttons to display the available target gas
labels for the toxic gas channel (H2S, CO, SO2, Cl2, NH3, CO2 (5.00%),
CO2 (10000 PPM), CO2 (5000 PPM), ***, and NOT USED).
6. Press the POWER/ENTER button to enter the new target gas label.
If you entered a label other than ***, continue with step 7. If you entered ***,
go to the next section, “Setting a custom target gas label.
7. To exit the Gas Combinations menu, press the SHIFT/
button until the
prompt is next to Channel 4, then press the SHIFT/
button again. The
ESCAPE message displays.
8. Press the POWER/ENTER button. The message SAVING DATA
displays, then the main menu displays.
Setting a custom target gas label
1. With the prompt next to the target gas label setting (***), press the
POWER/ENTER button. The rst asterisk ashes.
2. Press the AIR/
and SHIFT/ buttons to display the desired character.
Available characters are A through Z, 0 through 9, and a blank space.
3. Press the POWER/ENTER button to enter the displayed character. The
next character ashes.
4. Repeat steps 2 and 3 to enter the remaining characters. When you enter
the last character, the prompt ashes.
