Display Mode
The Eagle has four operating modes: normal operating mode, display mode,
setup mode, and calibration mode. With the Eagle in display mode, you can:
set user and station IDs
display peak readings
display elapsed time
display TWA and STEL readings (toxic gases only)
display battery voltage
display date and time (data logging option only)
clear the data log (data logging option only)
display remaining log time (data logging option only)
To enter display mode, from the normal screen press the DISP/ADJ button.
To scroll from one screen to the next press the DISP/ADJ button.
NOTE: Each screen displays for 20 seconds. If you do not press the DISP/
ADJ button to scroll to the next screen within 20 seconds, the Eagle
automatically returns to the normal operating screen.
User and Station ID Screen
This screen displays only if the user ID function is activated (see “Turning
the User ID Function On or Off” on page 39). Each ID contains 10
characters. Uppercase letters, numbers, asterisks (*) and a blank space are
available characters.
Use this screen to identify user, location, or other information. If your Eagle
has the data logging option, the User and Station ID provides a way to
identify the user and location of exposure. The User and Station ID are saved
to the Data Logger when you turn off the Eagle, so you can update the IDs for
each data logging session.
