Owner manual

65-2484RK-06 Multi Point Detector • 1
Overview
This manual describes the 65-2484RK-06 multi point direct connect detector. This manual
also describes how to install, start up, maintain, and calibrate the detector when it is used
with a gas monitoring controller. A parts list at the end of this manual lists replacement
parts and accessories for the detector.
Specifications
WARNING: Do not use this product in a manner not specified in this instruction
manual.
Table 1 lists specifications for the multi-point detector.
Table 1: Specifications
Target Gas LEL/O
2
/H
2
S/SO
2
, methane calibration standard for LEL
*Note: Since the 65-2484RK-06 is a direct connect detector, the
calibration is done at the controller.
Sampling Method Diffusion
Detection Range LEL: 0 to 100 %LEL (lower explosive limit)
O
2
: 0 to 25 %volume
H
2
S: 0 to 100 ppm (parts per million)
SO
2
: 0 to 6.00 ppm (parts per million)
Response Time 90% in 30 seconds
Accuracy Catalytic Combustible Gas
:
± 5% of reading or ± 2% LEL (whichever is greater)
Oxygen
:
± 0.5% O
2
Hydrogen Sulfide:
± 5% of reading or ± 2 ppm H
2
S (whichever is greater)
Sulphur Dioxide
:
± 10% of reading or ± 5% of full scale (whichever is greater)
Operating Temperature 23°F to 104°F (-5°C to 40°C)
