Owner manual

65-2484RK-06 Multi Point Detector • 25
Parts List
Table 5 lists replacement parts and accessories for the multi-point detector.
Table 3: Parts List
Part Number Description
06-1248RK-03 Calibration kit sample tubing, 3 ft. length
07-0033RK Detector housing cap gasket (for H
2
S and O
2
detectors)
61-0140RK Catalytic LEL replacement detector
65-1025RK Oxygen replacement plug-in sensor
65-2300RK-SO2 Replacement detector assembly, SO
2
(includes plug-in sensor)
65-2423RK-05 H
2
S replacement detector assembly (includes sensor)
65-2484RK-06 Multi-point detector assembly, LEL/O
2
/H
2
S/SO
2
65-2514RK Oxygen replacement detector assembly (includes sensor)
71-0233RK 65-2484RK-06 Multi Point Detector Operator’s Manual (this document)
81-0004RK Calibration cylinder, 50% LEL propane in air, 17 liter steel
81-0004RK-01 Calibration cylinder, 50% LEL propane in air, 34 liter steel
81-0004RK-03 Calibration cylinder, 50% LEL propane in air, 103 liter steel
81-0007RK Calibration cylinder, 15% LEL hexane in air, 34 liter steel
81-0007RK-01 Calibration cylinder, 15% LEL hexane in air, 103 liter steel
81-0012RK Calibration cylinder, 50% LEL methane in air, 17 liter steel
81-0012RK-01 Calibration cylinder, 50% LEL methane in air, 34 liter steel
81-0012RK-03 Calibration cylinder, 50% LEL methane in air, 103 liter steel
81-0018RK Calibration cylinder, 50% LEL isobutane in air, 17 liter steel
81-0018RK-01 Calibration cylinder, 50% LEL isobutane in air, 34 liter steel
81-0018RK-03 Calibration cylinder, 50% LEL isobutane in air, 103 liter steel
81-0076RK Zero air calibration cylinder, 17 liter steel
81-0076RK-01 Zero air calibration cylinder, 34 liter steel
81-0076RK-03 Zero air calibration cylinder, 103 liter steel
81-0078RK-01 Calibration cylinder, 100% nitrogen, 34 liter
81-0078RK-03 Calibration cylinder, 100% nitrogen, 103 liter
81-0090RK Calibration cylinder, 3-gas mix (CH
4
/ CO/ O
2
), 17 liter steel
81-0090RK-01 Calibration cylinder, 3-gas mix (CH
4
/ CO/ O
2
), 34 liter steel
