NOTE: If you do not allow the gas reading to decrease below the alarm points, then
unwanted alarms may occur.
9. Verify that the controller display reading decreases and stabilizes at 0 ppm.
10. Store the components of the calibration kit in a safe and convenient place.
Parts List
Table 3 lists replacement parts and accessories for the toxic detector.
Table 3: Parts List
Part Number Description
06-1283RK Calibration kit sample tubing, 3 foot teflon w/flexible tubing on ends
07-0125RK Detector housing cap gasket
18-0400RK-01 Junction box with rubber spacers
65-2300RK-ASH3 Replacement detector assembly, AsH
3
(includes plug-in sensor)
65-2300RK-CL2 Replacement detector assembly, Cl
2
, 0 - 3.00 ppm range
(includes plug-in sensor)
65-2300RK-CL-10 Replacement detector assembly, Cl
2
, 0 - 10.0 ppm range
(includes plug-in sensor)
65-2300RK-HCN Replacement detector assembly, HCN (includes plug-in sensor)
65-2300RK-NH3 Replacement detector assembly, NH
3
(includes plug-in sensor)
65-2300RK-PH3 Replacement detector assembly, PH
3
(includes plug-in sensor)
65-2300RK-SO2 Replacement detector assembly, SO
2
(includes plug-in sensor)
71-0146RK 65-2300RK/65-2301RK Operator’s Manual (this document)
81-0076RK Zero air calibration cylinder, 17 liter steel
81-0076RK-01 Zero air calibration cylinder, 34 liter steel
81-0076RK-03 Zero air calibration cylinder, 103 liter steel
81-0170RK-02 Calibration cylinder, 5 ppm SO
2
in nitrogen, 58 liter aluminum
81-0170RK-04 Calibration cylinder, 5 ppm SO
2
in nitrogen, 34 liter aluminum
81-0175RK-02 Calibration cylinder, 10 ppm NH
3
in nitrogen, 58 liter aluminum
81-0175RK-04 Calibration cylinder, 10 ppm NH
3
in nitrogen, 34 liter aluminum
81-0185RK-02 Calibration cylinder, 0.5 ppm PH3 in nitrogen, 58 liter aluminum, used to
calibrate PH
3
and AsH
3
detectors, see conversion factor on AsH
3
plug-in sensors
81-0185RK-04 Calibration cylinder, 0.5 ppm PH3 in nitrogen, 34 liter aluminum, used to
calibrate PH
3
and AsH
3
detectors, see conversion factor on AsH
3
plug-in sensors
