Instruction manual

1. OUTLINE
IMS01J04-E2
2
 Usable units (OMRON SYSMAC series)
Name Type
High-order link unit C200H-LK202-V1, C500-LK203, C120-LK202-V1
(SYSMAC C series), etc.
CPU unit with a built in
communication port
CPU unit of SYSMAC CS1 series
Serial communication board CS1W-SCB41 (SYSMAC CS1 series), etc.
 Usable modules (SR Mini HG SYSTEM)
The following function module data can be used in PLC communication (see “Data map” on page 24).
In addition, data on other modules connected (TI, AI, AO, etc.) can be used on one more
communication port (RKC communication or Modbus).
Function module Type
Temperature control module H-TIO-A H-TIO-B H-TIO-C H-TIO-D H-TIO-E
H-TIO-F H-TIO-G H-TIO-H H-TIO-J H-TIO-P
H-TIO-R
Position proportioning control
module *
H-TIO-K
Speed control module * H-SIO-A
Cascade control module * H-CIO-A
Current transformer input
module
H-CT-A (Up to 20 points/control unit are available)
* There is restriction on usable data. Only data described in 6.3 Communication Data List (P. 17)
can be used.
For the function modules, see the Hardware Quick Manual (IMS01V01-E) or Hardware
Instruction Manual (IMSRM15-E).
