8. CURRENT TRANSFORMER (CT) MONITOR
IMS01J04-E2
34
Continued from the previous page.
Unit address
setting
switch
PLC data
memory
address
Communication item
6
D9360 to
D9419
Unit address 6 Current transformer input measured value
CT1 to CT60
D9967 Unit address 6 PCP normal communication flag
7
D9420 to
D9479
Unit address 7 Current transformer input measured value
CT1 to CT60
D9968 Unit address 7 PCP normal communication flag
8
D9480 to
D9539
Unit address 8 Current transformer input measured value
CT1 to CT60
D9969 Unit address 8 PCP normal communication flag
9
D9540 to
D9599
Unit address 9 Current transformer input measured value
CT1 to CT60
D9970 Unit address 9 PCP normal communication flag
A
D9600 to
D9659
Unit address A Current transformer input measured value
CT1 to CT60
D9971 Unit address A PCP normal communication flag
B
D9660 to
D9719
Unit address B Current transformer input measured value
CT1 to CT60
D9972 Unit address B PCP normal communication flag
C
D9720 to
D9779
Unit address C Current transformer input measured value
CT1 to CT60
D9973 Unit address C PCP normal communication flag
D
D9780 to
D9839
Unit address D Current transformer input measured value
CT1 to CT60
D9974 Unit address D PCP normal communication flag
E
D9840 to
D9899
Unit address E Current transformer input measured value
CT1 to CT60
D9975 Unit address E PCP normal communication flag
F
D9900 to
D9959
Unit address F Current transformer input measured value
CT1 to CT60
D9976 Unit address F PCP normal communication flag
Data memory address D9960, D9977 to D9999: Do not use this address range
