8. CURRENT TRANSFORMER (CT) MONITOR
Current transformer (CT) monitor function monitors only current transformer input.
Control unit is configured with H-PCP-J module and H-CT-A module to do current transformer (CT)
monitor. Data of functional module other than the H-CT-A module cannot be used. In addition, set the
communication protocol to “OMRON SYSMAC series special protocol [Current transformer (CT)
monitor].”
Maximum number of current transformer input points
Maximum 60 points/control unit
Maximum 960 points/communication port of PLC
This section describes the system configuration, switch setting and communication data of
current transformer (CT) monitor. For the communication specifications and connections,
see the following section.
 For the communication specifications, see the 2. COMMUNICATION
SPECIFICATIONS (P. 3).
 For the connections, see the 3. CONNECTIONS (P. 4).
