7. DATA MAP
IMS01J04-E2
27
Continued from the previous page.
Unit
address
4
Unit
address
5
Unit
address
6
Unit
address
7
Name
D3240 to
D3259
D3740 to
D3759
D4240 to
D4259
D4740 to
D4759
PID/AT transfer CH1 to CH20
D3260 to
D3279
D3760 to
D3779
D4260 to
D4279
D4760 to
D4779
Temperature measured value (PV) CH1 to CH20
D3280 to
D3299
D3780 to
D3799
D4280 to
D4299
D4780 to
D4799
Heat-side manipulated output value CH1 to CH20
D3300 to
D3319
D3800 to
D3819
D4300 to
D4319
D4800 to
D4819
Cool-side manipulated output value CH1 to CH20
D3320 to
D3339
D3820 to
D3839
D4320 to
D4339
D4820 to
D4839
Current transformer input measured value
(H-CT-A module) CH1 to CH20
D3340 to
D3359
D3840 to
D3859
D4340 to
D4359
D4840 to
D4859
TIO status CH1 to CH20
D3360 to
D3379
D3860 to
D3879
D4360 to
D4379
D4860 to
D4879
Set value monitor CH1 to CH20
D3380 D3880 D4380 D4880 Request command
D3381 D3881 D4381 D4881 PCP communication status
D3382 D3882 D4382 D4882 PCP normal communication flag
D3383 to
D3389
D3883 to
D3889
D4383 to
D4389
D4883 to
D4889
Do not use this address range
D3390 D3890 D4390 D4890 Memory area number
D3391 D3891 D4391 D4891 Control RUN/STOP transfer
D3392 to
D3399
D3892 to
D3899
D4392 to
D4399
D4892 to
D4899
Do not use this address range
D3400 to
D3419
D3900 to
D3919
D4400 to
D4419
D4900 to
D4919
PV bias CH1 to CH20
D3420 to
D3439
D3920 to
D3939
D4420 to
D4439
D4920 to
D4939
Setting change rate limiter CH1 to CH20
D3440 to
D3499
D3940 to
D3999
D4440 to
D4499
D4940 to
D4999
Do not use this address range
 Unit address 8 to B (Group 3)
Unit
address
8
Unit
address
9
Unit
address
A
Unit
address
B
Name
D5000 to
D5019
D5500 to
D5519
D6000 to
D6019
D6500 to
D6519
Temperature set value (SV) CH1 to CH20
D5020 to
D5039
D5520 to
D5539
D6020 to
D6039
D6520 to
D6539
Alarm 1 set value CH1 to CH20
D5040 to
D5059
D5540 to
D5559
D6040 to
D6059
D6540 to
D6559
Alarm 2 set value CH1 to CH20
D5060 to
D5079
D5560 to
D5579
D6060 to
D6079
D6560 to
D6579
Heater break alarm set value CH1 to CH20
(H-CT-A module)
Continued on the next page.
