6. COMMUNICATION DATA
IMS01J04-E2
22
Continued from the previous page.
Name
Attri-
bute
Struc-
ture
Data range
Factory
set value
Request command
[H-PCP-J]
R/W U
0: Monitor
Command which requests the SR Mini HG
SYSTEM to write data such as temperature
measured values, etc. (attribute: RO) to the
PLC side.
The SR Mini HG SYSTEM always repeats
data writing until “1: Setting” or “2: Set
value monitor” is set to the request
command. The PCP communication status
is set to “1: Writing on monitor data”
during data transfer.
1: Setting
Command which requests the SR Mini HG
SYSTEM to read data such as temperature
set values, etc. (attribute: R/W or WO)
from the PLC side. Just when “1: Setting”
is set to the request command, the SR Mini
HG SYSTEM starts reading the data from
the PLC side.
The PCP communication status is set to
“2: Reading out setting data” during data
transfer. After the data is transferred, the
request command and PCP communication
status returns to “0: Monitor” and
“1: Writing on monitor data,” respectively.
2: Set value monitor
Command which requests the SR Mini HG
SYSTEM to write data such as temperature
set values, etc. (attribute: R/W) to the PLC
side. Just when “2: Set value monitor” is
set to the request command, the SR Mini
HG SYSTEM starts writing the data to the
PLC side.
The PCP communication status is set to
“3: Writing on setting data” during data
transfer. After the data is transferred, the
request command and PCP communication
status returns to “0: Monitor” and
“1: Writing on monitor data,” respectively.
0
PCP communication
status
[H-PCP-J]
RO U
1: Writing on monitor data
During monitor data of attribute RO is
written to PLC
2: Reading out setting data
During setting data of attribute R/W or
WO is read from PLC
3: Writing on setting data
During setting data of attribute R/W is
written to PLC

Continued on the next page.
