6.3 Communication Data List
 Name
: Item stored in the memory area.
[ ]: The functional module name that data becomes valid is written.
 Attributes
RO: At the time of request command “0: Monitor,” SR Mini HG SYSTEM writes in data.
(SR Mini HG SYSTEM  PLC)
R/W: At the time of request command “1: Setting,” SR Mini HG SYSTEM read out data.
At the time of request command “2: Set value monitor,” SR Mini HG SYSTEM
writes in data. (SR Mini HG SYSTEM  PLC)
WO: At the time of request command “1: Setting,” SR Mini HG SYSTEM read out data.
(SR Mini HG SYSTEM  PLC)
 Structure
C: Data for each channel U: Data for each unit address
Name
Attri-
bute
Struc-
ture
Data range
Factory
set value
Temperature set value
(SV) 
[H-TIO-, H-CIO-A]
R/W C
TC/RTD input:
Within input range (Within setting limiter)
Current/voltage input:
Within display scale range
(Within setting limiter)
0
The position
of the decimal
point differs
depending on
the input
range.
Motor speed set value 
[H-SIO-A]
Within display scale range
(Within setting limiter)
Alarm 1 set value 
[H-TIO-, H-CIO-A,
H-SIO-A]
R/W C
TC/RTD input:
Within input range or span range
Current/voltage input, H-SIO-A:
Within display scale range or span range
See Factory
set value
table of
Alarm 1/
Alarm 2
set value *
Alarm 2 set value 
[H-TIO-, H-CIO-A,
H-SIO-A]
R/W C
* Factory set value table of Alarm 1/Alarm 2 set value
Input type Alarm type Alarm 1 set value Alarm 2 set value
TC/RTD input
Process high alarm Input range (high limit) Input range (high limit)
Process low alarm Input range (low limit) Input range (low limit)
Deviation high alarm, Deviation
high/low alarm, Band alarm
50 C
1
50 C
1
Deviation low alarm

50 C
1

50 C
1
No alarm function Input range (high limit) Input range (low limit)
Current/voltage input
Process high alarm 100 (100.0) % 100 (100.0) %
H-SIO-
A
Process low alarm 0 (0.0) % 0 (0.0) %
Deviation high alarm, Deviation
high/low alarm, Band alarm
50 (50.0) % 50 (50.0) %
Deviation low alarm

50 (

50.0) %

50 (50.0) %
No alarm function 100 (100.0) % 100 (100.0) %
1
The position of the decimal point differs depending on the input range.
