Alcatel-Lucent OmniStack 6200 Stackable LAN Switches
ALCATEL-LUCENT OMNISTACK 6200 STACKABLE LAN SWITCHES To stay competitive, 21st century businesses must take advantage of new networking technologies that deliver quick and secure access to vital information from any location. Customers expect and demand that customizable user-centric services be securely provided over an always available environment, and they want to be able to access it from anywhere such as over the Internet.
Alcatel-Lucent OmniStack 6200 A compact, one unit (1U) high form factor, all in one stackable design and a comprehensive set of features makes the Alcatel-Lucent OmniStack 6200 perfect for: I Enterprise workgroups / LAN wiring closets I Edge deployments, small-/medium-sized businesses and branch offices I Power-over-Ethernet I Residential Ethernet access distribution devices (MDU) for triple play services delivery.
Alcatel-Lucent OmniStack 6200 DEDICATED RESILIENT STACKING RING OmniSwitch 6850 Alcatel-Lucent’s fixed configuration switches are part of Alcatel-Lucent’s enterprise portfolio that includes the OmniSwitch 7000 and 9000 series of modular aggregation and core switches. This portfolio offers a complete edge-to-core solution with high availability, intelligent performance, and enhanced security in an easy-to-manage, flexible and scalable package.
Alcatel-Lucent offers a comprehensive networking portfolio that provides a secure, feature rich, and cost effective end-to-end triple play Ethernet solution. It supports subscriber centric content increasing user satisfaction and opportunities for additional operator services and revenue.
F E AT U R E S Simplified manageability I I I I I I I I I I I I I I I I I I Dual image and multiple configuration file storage provides backup Industry standard CLI with a familiar interface reduces training costs Easy-to-use point-and-click web based element manager with built-in help for easy configuration of new technology features Remote telnet management or secure shell Port based, port mirroring for troubleshooting Human readable ASCII-based config files for offline editing and bulk configuratio
Alcatel-Lucent OmniStack 6200 Advanced security I I I I I I I I I I I I I I 802.1x port based user authentication with multiple host mode 802.1x multi-client, multi-VLAN* support for per-client authentication and VLAN assignment MAC-based authentication for non802.1x capable devices Transparent 802.1x BPDU forwarding when 802.
Alcatel-Lucent OmniStack 6200 Physical dimensions I OS-LS-6212/6212P/6224/6224U: 17.32 x 9.05 x 1.73 in., 44 x 23 x 4.4 cm (W x D x H) I OS-LS-6224P/48/48P: 17.32 x 12.99 x 1.73 in., 44 x 33 x 4.4 cm, (W x D x H) Weight I OS 6212: 2.65 kg, 5.84 lbs I OS 6212P: 3.0 kg, 6.61 lbs I OS 6224U: 3.5 kg, 7.7 lbs I OS 6248: 4.1 kg, 9.01 lbs I OS 6248P: 5.5 kg, 12.
Environment compliancy I RoHS - Restriction on Hazardous Substances in Electrical and Electronic Equipment I WEEE - Waste Electrical and Electronic Equipment Number of power supplies OmniStack 6200 family supports one internal AC power supply for chassis power and an external connector on rear of chassis for use with the backup power supply solution Input voltage & current ratings OS-LS-6212: Input, AC 100~240V 50Hz~60Hz. Output DC 12V/2.5A OS-LS-6224/6248/6224U: Input, AC 100~240V 50Hz~60Hz.
ORDERING INFO PART NUMBER I OS-LS-6212 I OS-LS-6224 I OS-LS-6248 PRODUCT DESCRIPTION Fast Ethernet L2+ stackable fixed configuration chassis in a 1U form factor consisting of 12, 24 or 48 10/100 RJ-45 ports, two 10/100/1000 RJ-45 ports and two combo ports. Combo ports consist of two additional 10/100/1000 RJ-45 and two mini-GBIC ports. MiniGBIC ports support Gigabit Ethernet MiniGBIC (SFP) optical transceivers, which can be ordered separately.
ORDERING INFO PART NUMBER PRODUCT DESCRIPTION 100FX SFP Transceivers I SFP-100-LC-MM 100BaseFX SFP transceiver with an LC type interface. This transceiver is designed for use over multimode fiber optic cable. I SFP-100-LC-15 100BaseFX SFP transceiver with an LC type interface. This transceiver is designed for use over single mode fiber optic cable up to 15km. I SFP-100-LC-SM40 100BaseFX SFP transceiver with an SC type interface.
IP Networking Infrastructure Alcatel, Lucent, Alcatel-Lucent and Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners. The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein. © 2007 Alcatel-Lucent. All rights reserved. P/N 031773-00 Rev E 6/07 www.alcatel-lucent.
