Instructions / Assembly

CG2065303-RG - ENGLISH P.6 20170615 V
Hardware List
Item Item name Diagram Qty
A Bolt M6 x 40 12
B Bolt M6 x 12 15
C Flange Nut M6 27
D Spring 1
E “R” Pin 2
F M8 Cup Nut 1
Assembly Procedures
Symbol: The following symbols will be shown in each procedure for indication of
tightening the bolt and nut if necessary.
Some steps may require the assistance of a friend.
Hand Tighten only at this time
Tighten with tools at this time
