Desperado 17.5 inch Grill MODEL# CG2065303-RG OWNER’S MANUAL ASSEMBLY AND OPERATING INSTRUCTIONS Tools required for assembly: (Not Included) Pliers, Philips Screwdrivers, Adjustable Wrench. Keep this manual for future reference. WARNING OUTDOOR USE ONLY. Never use grill indoors. Carbon Monoxide poisoning that can lead to death. CG2065303-RG - ENGLISH P.
WARNING ! ! Only use this grill on a hard, level, non-combustible, stable surface (concrete, ground, etc.) capable of supporting the weight of the grill. Never use on wooden or other surfaces that could burn. When the grill is in use, maintain a clearance of at least 36” (1 m) between the hot grill and any combustible materials, such as bushes, trees, wooden decks, wooden fences, buildings, etc. Do not place a hot grill under a roof overhang or in any other enclosed area.
WARNING ! ! When grilling, grease from meat may drip into the charcoal and cause a grease fire. If this should happen, close the lid to suffocate the flame. Do not use water to extinguish grease fires. Use caution when opening the lid. Keep hands, face and body a safe distance away. Flash flare ups may Never place more than 5 lbs (2.3 kg) on the front and side tables. Do not allow charcoal and/or wood to rest on the walls of the grill.
ASSEMBLY INSTRUCTIONS THANK YOU FOR PURCHASING THIS DESPERADO SMOKER Read all safety warnings & assembly instructions carefully before assembling or operating your grill. For assembly assistance, missing or damaged parts, please call Rankam customer service at 1-888-837-1380 (U.S. only), Monday thru Friday 8AM to 5PM Pacific Standard Time or email to customerservice@rankam.com (Proof of purchase will be required.) Inspect contents of the box to ensure all parts are included and undamaged.
Components 1. Chimney Cover 2. Handle 1 pc 5. Cooking grates 3. Axle 2 pcs 6. Ash Pan 2 pcs 9. Side Table 7. Air Vent 10. Wire Rack 13. Leg tube (short) 1 pc 1 pc 1 pc 8. Chimney 11. Leg tube (body) 14. Leg tube (long) 1 pc 1 pc 1 pc 2 pcs 4. Grill body 1 pc 12. Support plate 2 pcs 2 pcs 15. Wheels 2 pcs 2 pcs Stop! DO NOT RETURN TO RETAILER. For assembly assistance, missing or damaged parts, please contact Rankam customer service at customerservice@rankam.com or 1-888-837-1380.
Hardware List Item Item name Diagram Qty A Bolt M6 x 40 12 B Bolt M6 x 12 15 C Flange Nut M6 27 D Spring 1 E “R” Pin 2 F M8 Cup Nut 1 Assembly Procedures Symbol: The following symbols will be shown in each procedure for indication of tightening the bolt and nut if necessary. Hand Tighten only at this time Tighten with tools at this time Some steps may require the assistance of a friend. CG2065303-RG - ENGLISH P.
Step 1. Step 2. CG2065303-RG - ENGLISH P.
Step 3. Step 4. CG2065303-RG - ENGLISH P.
Step 5. Step 6. CG2065303-RG - ENGLISH P.
Step 7. Step 8. CG2065303-RG - ENGLISH P.
Step 9. Step 10. Tighten all hardware CG2065303-RG - ENGLISH P.
WARNING DO NOT use grill without charcoal ash pans in place. DO NOT attempt to remove charcoal ash pans while pan contains hot coals. ! WARNING ! Place the grill outdoors on a hard, level, non-combustible surface away from roof overhang or any combustible material. Never use on wooden or other surfaces that could burn. Place the grill away from open windows or doors to prevent smoke from entering your house. In windy weather, place the grill in an outdoor area that is protected from the wind.
Instruction for reference only: 1. Begin with three full sheets of newspaper. 2. Take 2 sheets of newspaper and roll each into a tube shape and then give them a little twist to form each of them into a straight rope like shape. Be careful to not twist too tight. 3. Turn the charcoal chimney starter over and place both pieces of rolled and twisted newspaper along the inside bottom of the charcoal chimney starter to form a complete circle.
If using a Charcoal Chimney Starter, follow all manufacturer’s warnings and instructions regarding the use of their product. Start with 2.2 lbs (1.0 kg) of charcoal. When charcoal is burning strong, carefully place hot coals in centre of each charcoal grate. Instruction for reference only: 1. Begin with three full sheets of newspaper. 2. Take 2 sheets of newspaper and roll each into a tube shape and then give them a little twist to form each of them into a straight rope like shape.
Flavouring Wood To obtain your favorite smoke flavour, experiment by using chunks, sticks or chips of flavour-producing wood such as hickory, pecan, apple, cherry, or mesquite. Most fruit or nut tree wood may be used for smoke flavouring. Do not use resinous wood such as pine as it will produce an unpleasant taste. Wood chunks or sticks 7 to 10 cm (3” to 4”) long and 2 to 4 cm (1” to 2”) thick work best.
AFTER-USE SAFETY ! WARNING ! Always allow grill and all components to cool completely before handling. Never leave coals and ashes in grill unattended. Make sure coals and ashes are completely extinguished before removing. Before grill can be left unattended, remaining coals and ashes must be removed from grill. Use caution to protect yourself and property. Place remaining coals and ashes in a non-combustible metal container and completely saturate with water.
LIMITED WARRANTY 1. Manufacturer warrants this Product to be free from defects in workmanship and materials for a period of Ninety (90) days from the date of purchase, PROVIDED claims are submitted, in writing, with proof of purchase. 2.
Should you encounter any problem or Obtaining replacement parts CALL US FIRST. Do not return product to the store. WE CAN HELP. Rankam (China) Manufacturing Co. Ltd. 18/F., New Lee Wah Centre, 88 Tokwawan Road, Kowloon, Hong Kong Please contact Rankam Customer Service at customerservice@rankam.com or at 1-888-837-1380, Mon to Fri, 8:00 a.m. – 5:00 p.m. Pacific Standard Time. CG2065303-RG - ENGLISH P.
