Aaching the 6 m heat duct
1. Tape the inner duct to the spigot plate. This ensures a secure attachment.
2. Tape the outer duct to the spigot plate. This keeps the outer duct from bunching and
touching the side of the replace. Ensure:
- a complete seal around the duct
- a smooth bend as the duct exits the appliance
- a 250 mm distance from the side of the unit to the duct bend, the spigot adaptor
automatically (if mounted correctly) provides this clearance
Tape inner duct to spigot. This
securely aaches the inner duct
to the spigot.
250 mm
The rst 6 m length of duct cannot be cut down. This will cause excessive heat to pass
through the fan.
IMPORTANT
Tape outer duct to spigot. Be
sure that no ducng touches
the replace.
Maintain 250 mm distance from side of
unit—ensure the duct does not come
into contact with the re.
Inner duct
Tape
Tape
Outer duct &
insulaon
Inner duct
Tape
Tape
Outer Duct &
Insulaon
