Key specications
For more information, please refer to DSG800 Data Sheet.
Frequency
Frequency range
DSG815 9 kHz to 1.5 GHz
DSG830 9 kHz to 3 GHz
Setting time < 10 ms (typ.)
Temperature stability With option OCXO-B08 < 5 ppb
Aging rate With option OCXO-B08 < 30 ppb/year
Amplitude
Maximum output level 100 kHz ≤ f ≤ 3 GHz +13 dBm, +20 dBm (typ.)
Level uncertainty
100 kHz ≤ f ≤ 3 GHz, +13 dBm to -60 dBm ≤ 0.9 dB, ≤ 0.5 (typ.)
100 kHz ≤ f ≤ 3 GHz, -60 dBm to -110 dBm ≤ 1.1 dB, ≤ 0.7 (typ.)
Setting time Fixed frequency, 20
℃
to 30
℃
≤ 5 ms (typ.)
Max. reverse power Max. DC voltage 50 V
Spectral Purity
Harmonic CW mode, 1 MHz ≤ f ≤ 3 GHz, level ≤ +13 dBm < -30 dBc
Non-harmonic
CW mode, level > -10 dBm, carrier offset > 10 kHz
100 kHz ≤ f ≤ 1.5 GHz < -60 dBc, < -70 dBc (typ.)
SSB phase noise
CW mode, carrier offset = 20 kHz
100 kHz ≤ f ≤ 1.5 GHz < -100 dBc/Hz, < -105 dBc/Hz (typ.)
Sweep
Sweep manner Frequency sweep, level sweep
Sweep type Step sweep, list sweep
Analog Modulation
Modulation type AM, FM, ØM, Pulse mod.
Modulation source Internal, external
External modulation
signal coupling
AC, DC
AM modulation depth 0% to 100%
FM Max. deviation 1 MHz
ØM Max. deviation 5 rad
Pulse modulation rise/fall
time (10%/90%)
< 50 ns, 10 ns (typ.)
Simultaneous Modulation
AM FM ØM Pulse mod. (opt.)
AM ― ○ ○
△
FM ○ ― × ○
ØM ○ × ― ○
Pulse mod. (opt.)
△
○ ○ ―
