RIGOL Chapter 2 Front Panel Operations
2-66 DP800 User’s Guide
Output Response
Output Off
Sensitivity
Low
Enable
No
Trigger Output
Data Line
D0
Control Source
CH1
Trigger Condition
Output Off
Output Signal
Level
Square
Period: 1s; Duty Cycle: 50%
Polarity
Positive
Enable
No
Store
Browser
Directory
Directory
C:\
File
The first file
File Type
*.rsf
Note*: These parameters are not affected by factory reset (when "Default" is selected in Utility
System Power On, restarting the power supply will restored it to the factory setting).
