RIGOL Chapter 1 Quick Start
1-16 DP800 User’s Guide
User Interface
DP800 series power supply provides three kinds of display modes (normal, waveform
and dial). The default is normal. You can press Display Disp Mode to select
different display mode. This section introduces the user interface layout under the
normal display mode (as shown in the figure below and
Table 1-4 on the next page).
Figure 1-6 User Interface (Normal Display Mode)
1 2 3 4 5
6
7
8
9
10
11
