RIGOL Chapter 2 Front Panel Operations
2-24 DP700 User’s Guide
Restore Default Settings
Restore the instrument settings to defaults if necessary, as shown in Table 2-3.
Operation Procedures:
1. Press Memory to enter the store and recall interface. By default, "Restore
defaults" is selected. You can also press the Up/Down/Left/Right arrow key or
use the knob to switch the parameter focus to "Restore defaults".
2. Press OK and select "YES" to restore the instrument settings to defaults, as
shown in Table 2-3.
Table 2-3 Default Settings
Model
DP711
DP712
Channel Parameter
Voltage/Current Setting Value 0 V/5 A 0 V/3 A
OVP/OCP Value 32 V/5.3 A 53 V/3.2 A
OVP/OCP On/Off Off/Off Off/Off
Output On/Off Off Off
System Setting
Beeper On
Screen Saver Off
Trigger Input Off
Trigger Output Off
RS232 Interface Setting
Baud Rate 9600
Stop Bit 1
Data Bit 8
Parity None
Timer
Number of Output Groups
1
Number of Cycles 1
Trigger Mode Auto
End State Output Off
Timing Parameter
Group ID: 1
Output Voltage: 1 V
Output Current: 1 A
Duration Time: 1 s
Tip
When "power-on setting" is set to "Default", it indicates that the instrument will
be restored to defaults once the instrument is powered on again.
