Parameter Setting Method
Most parameters can be set through the front panel operations. The common setting
methods are listed below. The setting method for certain parameters is different
from the methods below, refer to the relevant chapters of this manual for the further
explanation.
Method 1 (Num Key):
1. Press the Up/Down arrow key to switch the parameter focus, such as the voltage
setting value, the number of output groups for timer, etc.
2. Enter a value by using the num key.
While entering a value, press
to delete the unwanted character if necessary.
3. When setting the voltage, press the Up arrow key or OK to set the voltage unit
to V; press the Down arrow key to set the voltage unit to mV.
When setting the current, press the Left arrow key to set the current unit to mA;
press the Right arrow key or OK to set the current unit to A.
When setting other parameters, press OK to confirm it.
Method 2 (Knob):
1. Press the Up/Down arrow key to switch the parameter focus, such as the voltage
setting value, the number of output groups for timer, etc.
2. Press the Left/Right arrow key to move the cursor to a desired position.
3. Rotate the knob to modify the value.
Tip
The help information of the currently displayed interface is displayed in real time at
the bottom of the interface. You can also refer to the help information to set or
modify the parameters.
