General Specifications
Display
Type Black and White LCD Screen
Resolution 256 Horizontal x 64 Vertical
Grey Degree 4 Grey Level
Contrast (typical) 150 : 1
Light (typical) 300 nit
Power
Supply 100-240 VAC
RMS
, 45-440Hz, CAT II
Consumption Less than 40W
Fuse 2A, T Level , 250V
Environment
Operation：10 ~+40℃℃
Temperature Range
Non-operation：-20 ~+60℃℃
Cooling Natural cooling
Below +35℃：≤90％ relative humidity
Humidity Range
+35 ~+40℃℃：≤60％relative humidity
Operation : below 3,000m Height Range
Non-operation: below 15,000m
Instrument Specifications
Width 232mm
Height 108mm
Dimension
Depth 288mm
Package excluded 2.65 Kg Weight
Package Included 4Kg
IP Protection
IP2X
Calibration Interval
One year suggested
