Counter Specification
Function Frequency, period, positive/negative Pulse width, Duty cycle
Frequency range Single channel: 100mHz ~ 200MHz
Frequency resolution 6 digits/second
Voltage range and sensitivity (not modulated signal)
Auto mode: 1Hz to 200MHz
200 m
VPP to 5 VPP
DC offset range
±1.5 V
DC
100mHz~100MHz
20m V
RMS to ±5 Vac+dc
DC
100MHz~200MHz
40m V
RMS to ±5 Vac+dc
1Hz~100MHz
50m
VPP to ±5 VPP
Manual mode
AC
100MHz~200MHz
100m
VPP to ±5 VPP
Pulse width and
Duty cycle
measure
1Hz to 10MHz (100m
VPP ~ 10VPP)
Input impedance 1MΩ
Coupling mode
AC、DC
High frequency restrain
High frequency noise restrain (HFR)
on or off
Input adjust
sensitivity
Low, Medium, High
The trigger level can adjust manually/ automatically
Trigger level range: ±3 V (0.1% to 100％)
Trigger mode
Resolution: 6 mV
