Sweep (CH1)
Carrier Waveforms Sine, Square, Ramp, Arb(Except DC)
Type Linear or Logarithmic
Direction Up or Down
Sweep Time 1 ms to 500 s ± 0.1%
Source Internal/External/Manual
Burst (CH1)
Waveforms Sine, Square, Ramp, Pulse, Noise, Arb(Except DC)
Types Count (1 to 50,000 periods), infinite, gated
Start Phase -360° to +360°
Internal Period 1 µs – 500s ± 1%
Gate Source External Trigger
Trigger Source Internal/External/Manual
Rear Panel Connector
External AM Modulation ± 5 VPK = 100% modulation
5kΩ input impedance
External Trigger TTL-compatible
Trigger Input
Input Level TTL-compatible
Slope Rising or falling (selectable)
Pulse Width > 100 ns
Input Impedance > 10 kΩ, DC coupled
Linear Sweep < 500 µs (typical)
Latency Sweep < 500 ns (typical)
Trigger Output
Level TTL-compatible into >1kΩ
Pulse Width > 400ns typical
Output Impedance 50Ω, typical
Maximum Rate 1 MHz
Sync Output (CH1)
Level
TTL-compatible into >1kΩ
Pulse Width
> 50ns (typical)
Output Impedance
50Ω (typical)
Maximum Frequency
2 MHz
