Data Sheet

标题 文件密级：内部公开
2008-6-25 RIGOL 机密，未经许可不得扩散 第 3 页，共 6 页
kHz)
<100kHz
0.1 dB (± 1%)
<100kHz
0.1 dB (± 1%)
100kHz ~ 5MHz
0.15 dB (± 1.5%)
100kHz ~ 5MHz
0.15 dB (± 1.5%)
Amplitude Flatness (sine wave
relative to 1 00kHz)
5MHz ~ 20MHz
0.3 dB (± 3.5%)
5MHz ~ 20MHz
0.3 dB (± 3.5%)
DC Offset CH1 CH2
Range (peak AC＋DC)
±5V （50Ω）
±10 V （
High Z）
±1.5V （50Ω）
±3 V （High Z）
Accuracy ± 2% of the Offset Setting
± 0.5% (|Voffset|) of the
Amplitude ± 2mV
± 2% of the Offset Setting
± 0.5% (|Voffset|) of the
Amplitude ± 2mV
Waveform Output CH1 CH2
Impedance 50 Ω typical
50 Ω
typical
Protection Short-circuit protected; Overload
disables the output automatically
none
AM (CH1)
Carrier Waveforms Sine, Square, Ramp, Arb(Except DC)
Source Internal/ External
Modulating Waveforms Sine, Square, UpRamp, DnRamp,Triangle, Noise, Arb (2mHz to 20kHz)
Depth 0% - 120%
FM (CH1)
Carrier Waveforms Sine, Square, Ramp, Arb(Except DC)
Source Internal/ External
Modulating Waveforms Sine, Square, UpRamp, DnRamp,Triangle, Noise, Arb (2mHz to 20kHz)
Frequency Deviation DC~ 5 MHz
PM (CH1)
Carrier Waveforms Sine, Square, Ramp, Arb(Except DC)
Source Internal/ External
Modulating Waveforms Sine, Square, UpRamp, DnRamp,Triangle, Noise, Arb (2mHz to 20kHz)
Phase Deviation 0 to 360°
FSK (CH1)
Carrier Waveforms Sine, Square, Ramp, Arb(Except DC)
Source Internal/ External
Modulating Waveforms 50% duty cycle square (2mHz to 50kHz)
