20 kHz to 100 kHz -70 dBc -60 dBc
100 kHz to 1 MHz -55 dBc -50 dBc
1 MHz to 10 MHz -45 dBc -40 dBc
Total Harmonic Distortion DC to 20 kHz,1Vpp <0.2%
Spurious (non-harmonic)
DC to 1 MHz < -70 dBc
1 MHz to 10 MHz < -70 dBc + 6 dB/octave
Phase Noise 10kHz Offset –115 dBc / Hz (Typical)
Square Wave
Rise/Fall Time < 20 ns (10% to 90%), Typical, 1kHz 1Vpp
Overshoot < 5% (Typical, 1kHz 1Vpp)
1µHz to 3MHz 20% to 80%
3MHz(not contain) to 4MHz 40% to 60%
Duty Cycle
4MHz (not contain) to 5MHz 50%
Asymmetry
(below 50% Duty Cycle)
1% of period+ 20ns
Jitter 6ns + 0.1% of period
Ramp Wave
Linearity < 0.1% of peak output (typical, 1KHz, 1Vpp, 100% Symmetry)
Symmetry 0% to 100%
Pulse Wave
Pulse Width 2000s max period; 20ns min period; 1ns resolution
Overshoot < 5%
Jitter 6ns + 100ppm of period
Arb Wave CH1 CH2
Waveform Length 4k points 1k points
Amplitude Accuracy 14 bits (including sign) 10 bits (including sign)
Sample Rate 100MSa/s 100MSa/s
Minimum Rising /Falling Time 35ns 35ns
Jitter (RMS) 6 ns + 30ppm 6 ns + 30ppm
Non-Volatile Storage (Total:10
Waveforms)
10 waveforms 10 waveforms
Output CH1 CH2
Amplitude
2 mVPP ~ 10 VPP （50 Ω）
4 mVPP ~ 20 VPP （High Z）
2 mVPP ~ 3 VPP （50 Ω）
4 mVPP ~6 VPP （High Z）
Amplitude Accuracy (100
± 1% of setting ± 1 mVPP ± 1% of setting ± 1 mVPP
