UNDER DASH MODULE WIRING
CONNECTOR A – ACCESSORY PLUG
PIN 4: +VDC INPUT
A. Input power for the under dash module to be wired to the factory ignition circuit or any +VDC trigger.
Note: The input power will also trigger the backlighting on dash controller. If the under dash module is wired to
constant +VDC the backlighting on the dash controller will always stay on.
Pin 3: GPS
A. Input for GPS Module (Sold Separately). This is required to activate the Adaptive mode.
Pin 2: Aux Switch Trigger – Projecting LED’s
A. Use any auxiliary +12v input to trigger projecting LED’s without the use of the Adapt dash controller.
B. The Adapt system will store the previously defined mode set by the Adapt dash controller. If the dash controller
is removed, this feature can be used to trigger the main projecting lights with any OE/aftermarket switch.
C. To program this feature simply plug in the Adapt dash controller to the under dash module and select your
desired projecting mode and backlighting color. With the projecting mode and backlighting color activated
remove the Adapt dash switch and cycle the auxiliary switches on/off. Now the selected modes are saved an
can be controlled by the auxiliary switches. To change the setting plug the Adapt dash controller back into the
under dash module and change to the desired mode.
